FILTERK Pleated Bag Filter 150x1000mm for Asphalt Plant

Large Image : FILTERK Pleated Bag Filter 150x1000mm for Asphalt Plant

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	FILTERK Bag Filter For Asphalt Plant
Certification:	ISO9001:2008
Model Number:	Bag Filter For Asphalt Plant

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

FILTERK Pleated Bag Filter 150x1000mm for Asphalt Plant

Description

Filtration Efficiency:	99.99%	Filtration Grade:	Hepa Filter
Medium Material:	Polyester + PTFE	Porosity:	0.01um
Diameter:	150mm	Height:	1000mm
Weight:	3KG	Filtering Area:	2.3 M2
Service Life:	≥6 Months	Operating Temperature:	≤135℃
Filtering Precision:	0.3-0.5μm	Construction:	Pleated Bag Filter
Material Coating:	PTFE Coating	Pleat Type:	Wide And Shallow
Installation Type:	Integrated Design
Highlight:	pleated bag filter for asphalt plant , 150x1000mm cartridge filter element , asphalt plant bag filter with warranty

FILTERK Pleated Bag Filter for Asphalt Plant

Product Specifications

Condition	New
Filtration Efficiency	99.99%
Construction	Bag Filter For Asphalt Plant
Filtration Grade	HEPA Filter
Medium Material	Polyester with PTFE Coating
Porosity	0.01μm
Dimensions (OD×H)	150mm × 1000mm
Weight	3KG
Warranty	3 Months
Filtering Area	2.3 m²
Service Life	≥6 months
Operating Temperature	≤135℃
Filtering Precision	0.3-0.5μm
OEM Available	Yes

Key Features

100% fine sand bonded polyester construction
Wide and shallow pleated design
Multiple specifications available for different requirements
High filtration efficiency up to 99.99%
Integrated design for quick and easy installation and maintenance
Compatible with various tube sheet specifications
Top and bottom sealed with special materials
Optional surface treatments including PTFE coating and anti-static

Application Environments

Cement and Rock Processing:

Crushing/Grinding Coal Mill Raw Mill/Cement Mill Clay Crushing Packaging Machines Bentonite Processing Kaolin Processing Silo Ventilation Material Handling

Aluminum Plants:

Fluidized Bed Dry-Cleaning Venturi Jet Dry-Cleaning Self-Baking Dry-Cleaning Carbon Dust Processing Anode Processing

Food & Medical:

Food Additives Cereal Drying Protein Spray Drying Grain Processing Flour Production Animal Vitamins Pharmaceuticals

Metallurgy:

Electric Arc Furnace Blast Furnace Sulfur Removal Casting Machines Induction Furnace Mold Cooling

Chemical Industry:

Fertilizer Production Plastic Fiber Bleaching Powder Cellulose Polyethylene Resin Polystyrene

Paint & Pigment:

Powder Mixing Packaging Lines Pneumatic Conveying Paint Mixing Pigment Processing Spray Drying
